Cisco C9105AXW-E wireless access point Gray Power over Ethernet (PoE)

Catalyst 9105AXW-E Wireless Access Point, Wi-Fi 6, 2x2 MU-MIMO, Controller Managed, PoE, Wall Mount (Wall Plate included) (C9105AXW-E)

Key Features

• COMPACT AND POWERFUL: 2x2 MU-MIMO Wi-Fi 6, up to 1.49 Gbps data rate, optimised power consumption
• IOT-READY: Embedded IoT radios enabling BLE 5.0 and Zigbee, custom IoT app hosting with Docker-style containers
• DEPLOYMENT OPTIONS: Two form factors to choose from. Ceiling mount for best coverage (C9105AXI) and wall mount for ease of installation and expanding wired connections (C9105AXW)
• PEACE OF MIND: 90-day software and limited lifetime hardware warranty

Description

The most versatile Cisco Catalyst 9105 Access Points goes beyond the Wi-Fi 6 (802.11ax) standard, offers high-density and resiliency, as well as network intelligence and IOT Application hosting. It comes with ceiling mount for remote workers, branch offices and small to medium-size deployments, and wall mount for hospitality, residence halls and other multi-dwelling units.

Specifications

Performance
Ethernet LAN data rates	10,100,1000 Mbit/s
2.4 GHz	Yes
5 GHz	Yes
Country of origin	Mexico
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g
MIMO type	Multi User MIMO
MIMO	Yes
Features
Ethernet LAN data rates	10,100,1000 Mbit/s
2.4 GHz	Yes
5 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g
Maximal-Ratio Combining (MRC)	Yes
Cyclic Shift Diversity (CSD)	Yes
MIMO type	Multi User MIMO
MIMO	Yes
Ports & interfaces
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	1
Power
Power over Ethernet (PoE)	Yes
Power plug type	Type C
Design
Country of origin	Mexico
Product colour	Gray
Antenna
Antenna type	Internal
Technical details
Products per shipping (inner) case	1 pc(s)
Harmonized System (HS) code	85176990
Software
Maximal-Ratio Combining (MRC)	Yes
Cyclic Shift Diversity (CSD)	Yes
Weight & dimensions
Width	3.54" (90 mm)
Depth	6.3" (160 mm)
Height	1.29" (32.7 mm)
Weight	13.2 oz (373.2 g)
Package width	8.69" (220.7 mm)
Package depth	9.44" (239.8 mm)
Package height	2.75" (69.8 mm)
Package weight	22.9 oz (648.5 g)
Packaging data
Package width	8.69" (220.7 mm)
Package depth	9.44" (239.8 mm)
Package height	2.75" (69.8 mm)
Package weight	22.9 oz (648.5 g)
Number of products included	1 pc(s)
Packaging content
Number of products included	1 pc(s)
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-30 - 70 °C
Logistics data
Products per master (outer) case	1 pc(s)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
