HPE ARUBA 6200M 24G 4SFP+ REMAN SW Gigabit Ethernet (10/100/1000) 1U Black

Aruba Networking CX 6200M 24G 4SFP+ Switch Reman

Key Features

• Enterprise-class connectivity with support for ACLs, robust QoS and common protocols such as static and Access OSPF
• routing Scalability with 8-member switch VSF stacking
• Scalability with 8-member switch VSF stacking for up to 384 downlink ports
• Versatile 1G/10G uplinks with LRM and MACsec 256 support on modular switches
• Convenient built-in 1G/10G uplinks on fixed power switches and additional cost-efficient 1G uplink switch models
• Industry standard Power over Ethernet with up to 30W PoE (Class 4) per port on fixed power switches and up to 60W
• PoE (Class 6) per port on modular power switches
• Intelligent monitoring, visibility, and troubleshooting with HPE Aruba Networking Network Analytics Engine
• Manage via single pane of glass with HPE Aruba Networking Central across wired, wireless, and WAN
• Simple, one touch deployment with the HPE Aruba Networking CX Mobile App
• Automated configuration and verification with HPE Aruba Networking NetEdit
• Secure and simple access for users and IoT with HPE Aruba Networking Dynamic Segmentatation

Description

The HPE Aruba Networking CX 6200 Switch Series is a next-generation family of stackable access switches ideal for enterprise branch offices, campuses, and SMB networks. With a cloud-centric design that combines a fully programmable operating system (OS) with the HPE Aruba Networking CX Network Analytics Engine, this switch family extends industry-leading deployment, monitoring, and troubleshooting to the access layer. Prepare your network for future demands with a powerful Gen7 ASIC that delivers an AI and Wi-Fi 7 ready, non-blocking performance. HPE Aruba Networking Virtual Stacking Framework (VSF) allows for stacking of up to 8 switches, providing scale and simplified management. This series includes fixed (CX 6200F) and modular (CX 6200M) switches with built-in high-speed uplinks and up to 1440W of PoE to support Internet of Things (IoT) devices such as security cameras and wireless APs.

What is new supporting point:
Enterprise-class connectivity with support for access control lists (ACLs), robust quality of service (QoS), and common protocols such as static and access OSPF routing
Up to 384 ports of scalability with 8-member HPE Aruba Networking Virtual Stacking Framework (VSF) stacking supported for both 24 and 48-port fixed and modular switches through the CX installer app
Flexible, modular switch models support hot-swappable, redundant power supplies and fans for enhanced resiliency
Real-time insights and actions through a built-in network analytics engine to securely maintain network performance, stability, and security
Dynamic segmentation enhanced with application-based policy to deliver secure access for users and Internet of Things (IoT)
HPE Aruba Networking Switch Multi-Edit Software supports for automation, configuration and verification

Specifications

Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity	4
USB Type-A ports quantity	1
Copper ethernet cabling technology	1000BASE-T
Network
Copper ethernet cabling technology	1000BASE-T
Ethernet LAN data rates	10,100,1000 Mbit/s
10G support	Yes
Data transmission
Switching capacity	128 Gbit/s
Throughput	95.2 Mpps
Latency (1 Gbps)	2.28 µs
Latency (10 Gbps)	1.46 µs
Design
Rack mounting	Yes
Stackable	Yes
Product colour	Black
Form factor	1U
Performance
Physical stacking (units)	8
Processor frequency	1800 MHz
Memory type	DDR4-SDRAM
Internal memory	8000 MB
Processor manufacturer	ARM
Built-in processor	Yes
Processor model	ARM Cortex-A72
Stackable	Yes
Power
AC input voltage	200 - 240 V
Power consumption (typical)	75 W
Input voltage	230 V
Power source	AC
Power over Ethernet (PoE)
Power over Ethernet (PoE)	No
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Weight & dimensions
Width	1.73" (43.9 mm)
Depth	17.4" (442.5 mm)
Height	15.1" (383.8 mm)
Weight	13.2 lbs (6.01 kg)
Other features
Input voltage	230 V
Ethernet LAN data rates	10,100,1000 Mbit/s
