Grandstream Networks GWN7701PA network switch Unmanaged Gigabit Ethernet (10/100/1000) Black

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at; IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at

Description

The GWN7700 series are unmanaged network switches that provide a quick and cost-effective way to add high-speed Gigabit connectivity to home offices and small/medium businesses. It requires no configuration or installation, offers a desktop and wall-mountable design, and provides auto MDI/MDIX to eliminate the need for crossover cables. Each port supports auto-negotiation to allow the GWN7700 series to recognize the link speed of any 10/100/1000Mbps network device and intelligently adjust for compatibility and optimal performance. The PoE (Power-over-Ethernet) models provide ports with IEEE 802.3af/at compliant, smart dynamic PoE output to power IP phones, IP cameras, Wi-Fi access points, and other PoE endpoints. The plug-and-play GWN7700 series are the ideal unmanaged network switches for home offices and small-to-medium businesses.

Specifications

Management features
Switch type	Unmanaged
Quality of Service (QoS) support	Yes
Multicast support	Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity	1
Network
Networking standards	IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Active link detection	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
10G support	No
Auto-negotiation	Yes
IGMP snooping	Yes
Data transmission
Switching capacity	16 Gbit/s
Jumbo frames	9000
Jumbo frames support	Yes
Security
IGMP snooping	Yes
Multicast features
Multicast support	Yes
Design
Rack mounting	Yes
Product colour	Black
LED indicators	Activity, Power
Power
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	150 W
Power source	AC
Power over Ethernet (PoE)
Power over Ethernet (PoE)	No
Power over Ethernet (PoE) ports quantity	8
Weight & dimensions
Width	7.09" (180 mm)
Depth	11" (280 mm)
Height	1.73" (44 mm)
Weight	3.31 lbs (1.5 kg)
Packaging data
Package width	8.31" (211 mm)
Package depth	14.4" (366 mm)
Package height	2.09" (53 mm)
Package weight	4.63 lbs (2.1 kg)
Performance
Auto-negotiation	Yes
Other features
Ethernet LAN data rates	10,100,1000 Mbit/s
