HPE Aruba Networking Aruba AP-318 (RW) 1733 Mbit/s Power over Ethernet (PoE)

Aruba AP-318 (RW) 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xRPSMA Connectors Indoor Hardened AP, Remanufactured

Description

The hardened Aruba 318 series access point delivers gigabit Wi-Fi performance to 802.11ac mobile devices in harsh, weather-protected environments such as warehouses, industrial freezers or enclosures in extreme environments such as stadiums.

Delivers 4x4:4SS MU-MIMO capability, Aruba’s advanced ClientMatch and an integrated Bluetooth beacon to enable Aruba location services.

Specifications

Performance
Maximum data transfer rate	1733 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Spread spectrum method	DSSS, OFDM
2.4 GHz	Yes
5 GHz	Yes
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Features
Maximum data transfer rate	1733 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Spread spectrum method	DSSS, OFDM
2.4 GHz	Yes
5 GHz	Yes
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Security
Security algorithms	IPSec
Ports & interfaces
USB connector type	Micro-USB
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	1
Power
Power consumption (typical)	23 W
Power over Ethernet (PoE)	Yes
Design
Internal	No
Placement	Wall
Cable lock slot	Yes
Cable lock slot type	Kensington
Antenna
Number of connectors	6
Antenna connector type	RP-SMA
Technical details
Harmonized System (HS) code	85176990
Weight & dimensions
Width	5.91" (150 mm)
Depth	8.74" (222 mm)
Height	2.95" (75 mm)
Weight	2.71 lbs (1.23 kg)
Operational conditions
Operating relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	-40 - 60 °C
Storage temperature (T-T)	-40 - 70 °C
Operating altitude	0 - 118110.2" (0 - 3000 m)
Logistics data
Harmonized System (HS) code	85176990
